KTM RC250R

Now now, do not get too excited just yest. This is not a street model from KTM in the 250 market, but this is the Moto 3 bike that has been made for the public to own with a price tag that most people can’t  even afford. But hey, this is almost identical to the Moto3 bike that you see on the Moto3 race even though it has some reduced specs but it is possible to make this production race bike in the same way as the Moto3 bike too.

Well if you are ever interested in owning such bike, the price to pay is USD54,000 which is  roughly around RM166,000 without even considering all the wonderful taxes we have for automobile goods. Well let’s just say, you have to be almost a millionaire in Malaysia just to own such bike. But from this bike, we can at least predict that there will be a street model of KTM in the future to cater a small displacement sportsbike.

Below is the spec to the bike:

TECHNICAL DATA OF THE KTM RC 250 R (Production Racer 2013)

DRIVE
Motor: Single cylinder, 4-stroke motor, DOHC
Displacement: 249.5 ccm
Bore/Hub: 81/48.5 mm
Performance: min. 37 kW at 13.000 revs/min
Max. Torque: 28 Nm at 11.000 revs/min
Compression ratio: 14,5:1
Starter/Battery: External starter / 12 V 0.8 Ah
Transmission: Cassette transmission, 6 gears, 3 options
Mixture preparation: Oval throttle body, 2 injection jets, Ø 50 equivalent
Cooling: Water cooler + oil-water heat exchanger
Generator: 12 V / 70 W
Lubrication: Semi-dry sump, 1 pressure and 2 suction pumps
Primary drive: Straight toothed: 2 transmission options
Valve drive: chain driven, intermediate wheel, radial arranged valves and DLC coated rocker arms
Clutch: Multiple disk clutch in oil bath
Motor management/ignition: GET by Athena ECU, GET by Athena Software MAYA EVO, adjustable motor brake/traction control/launch control/fuel mapping/ignition mapping/pit lane limiter, automatic switch, Interface for data recording

CHASSIS
Frame: Steel tubular frame, steering head and adjustable swing arm pivot
Subframe: one piece Wethje carbon subframe
Swing arm: Upside down formed, welded aluminum
Handlebar: Full aluminum clamps, exchangeable handlebar
Front suspension: WP RCMA 3548 fork Ø35 mm, adjustable spring preload suspension, compression and rebound damping adjustable over 20 levels
Rear suspension: WP BAVP 4618 shock absorber, adjustable length, hydraulic preload adjuster, High-/Low-Speed- compression damping and rebound damping over 20 levels
Triple clamp: cast aluminum, adjustable, 28/30 mm offset
Front brakes: Brembo single disk braking system 290 mm, radial brake caliper and radial hand brake cylinder
Rear brakes: Braking-brake disks 190 mm, Formula radial brake caliper and formula brake cylinder
Front/rear wheels: OZ forged aluminum 2.5 x 17’’ / 3.5 x 17’’
Tires front and rear: Dunlop 95/75-R17 / 115/75-R17 Moto3 M Slick
Chain: 415 chain, rear sprocket 16 – 18T, rear sprocket 34 – 42T
Silencer: Akrapovic Full Titanium System with silencer 107 dB (open), additional dB killer 100/103 dB
Steering head angle: ± 1° with optional steering head insets
Steering head position: ± 6 mm with optional steering head insets
Wheel base: 1210 mm ± 35 mm
Ride height: adjustable ± 6 mm
Seat height: 760 mm, adjustable ± 6 mm
Tank capacity: approx. 10.5 l
Weight without fuel: approx. 82 kg

Well with all that, we can say that it is a very good deal if you have the mean to pay for such price for the production racer. We can only imagine that it would make a fine trackday bike and yes it will be a fine race bike too. With that, please stay tune with us in Malaysian Riders and please LIKE our FACEBOOK PAGE and SUBSCRIBE to our YOUTUBE CHANNEL for more of our updates.
